We are one of the renowned manufacturers of Corrugated Box Packaging Machine from Mumbai, Maharashtra, India.
We supply Corrugated Box Packaging Machine in all parts of world. We manufacturers and export Corrugated Box Packaging Machine, Corrugated Box machine, Box Packaging Machine.

Details:

We manufacture a wide assortment of punching heavy duty corrugated box machine and Heavy Duty Platen Punching Machine that are widely used in various industries. These are manufactured using qualitative material sourced form trusted vendors. We offer our entire range is the following specifications:

The Jumbo Platen Punching Machine we offer are precisely designed for perfection. These Jumbo Platen Punching Machine have gained huge appreciation in the market for their host of qualitative features. Our gamut is available in the following specifications: Model No: Inside Chase Size Platen Size Impressions Per hours Min. Max. H.P. Req. Power Exerted Floor Space Required Gross Weight (App.) Dimensions (m) Shipping Volume (m³) C- EXPORT 86 52 x 82 in. 1321 x 2083 mm. 56 x 86 In. 1422 x 2184 mm. 800 1000 20 H.P 580 Ton 95 x 120 in. 17.00 M T 3.0 X 3.3 X 2.7 26.7 CBM

THE MENTIONED PRICE IS 40 X 55 IN, EXPORT MODEL  Century machines backed by the experienced and expertise of J. S. Dadiala is an organization committed to quality and innovation. Century machines are widely acclaimed as manufacturers and exporters of “world class export model extra heavy duty die cutting & creasing platen punching machines” conforming to international standards. The company has achieved a pioneering status in the feld of platen punching machines. Century machines aims at total customer satisfaction with strong focus on quality. Excellent infrastructure facilities and skilled man power enables the company to manufacture machines of international standards. Inside Chase Impressions per hour H. P. Req. Power Extended Floor Space Req. Gross Wt. App. (M.T.) Shipping Dimensions (m) Shipping Volume (m2) CBM  Min. Max.20 * 26 in 506 * 660 mm 1680 1800 3 200 Ton 58"* 58" .8 1.5 * 1.8 * 1.5 4.0 22 * 32 in 506 * 660 mm 1620 1740 5 220 Ton 60" * 61" .2 1.5 * 2.0 * 1.5 4.5 25 * 36 in 506 * 660 mm 1560 1690 5 250 Ton 63" * 67" 4 1.6 * 2.3 * 1.6 5.9 30 * 40 in 506 * 660 mm 1380 1500 7.5 285 Ton 70" * 76" 5.5 1.8 * 2.4 * 1.6 7.0

We offer a wide gamut of Die Platen Punching Press that are manufactured using latest technology and the entire process is stringently monitors so that their quality meets the industry standards. Model No: Inside Chase Size Platen Size Impressions Per hours H.P. Req. Power Exerted Floor Space Required Gross Weight (App.) Dimensions (m) Shipping Volume (m³) C- EXPORT 76 52 x 72 in. 1321 x 1829 mm. 55 x 76 In. 1397 x 1930 mm. 960 1080 15 H.P. 450 Ton 88x 111 In. 13.5 M T 2.8 X 3.1 X 2.1 18.2 CBM

Two Paper Reels – Fluting media & liner paper & starch base gum. Powder mixed with water in liquid form. To start the Heaters as heating time is around 40 minutes. Set the Flute roller according to the paper’s thickness – set gum unit & finally set pressure roller, we get 2 Ply. Keep the speed in control to minimize the wastage. Control the breaks of both paper reels for even unwinding. The finish 2 Ply Corrugated paper can be Re-winded for keeping in 2 Ply Roll form. If the cutting size is ready it can cut into require length with the help on online 2 Ply Rotary Sheet Cutter.



Use of Box Stitching Machine: This Machine is used to give the cartons final and perfect shape. Specification: This Machine is meant to stitch the corrugated boxes The machine is driven by coil spring clutch The pulley of the machine runs at the speed of 350 rpm so we can stitch maximum 350 pins per minutes The machine is fitted with thickness setter to adjust the gap depending on the board thickness The parts are standardized and are inter changeable and made of alloy steel This machine is exclusively designed for accuracy and quality stitching This machine is available in Straight/Angular/Bottom models Size Motor H.P. Weight App. (tons) Floor Space 65"x75" 2.0 10 5.5'x6.5' 65"x105" 2.0 1.2 5.5'x9.0'

Sheet Pasting Machine is meant for glueing the fluted side of two ply board to make the corrugated board of different plies.
